Analog Way to take ISE 2012 your latest presentation solutions

Analog Way, specialist in the design and manufacture of image converters and mixers, will be present among the 31 January and the 2 February 2012 at Integrated Systems Europe (Ise), the audio product fair, video and new technologies, where it will publicize its latest proposals for broadcast and presentation environments.

Analog Way will present its latest production and presentation solutions at ISE 2012, which will hold a new edition at the Amsterdam Rai venue, between the days 31 January and 2 February 2012

One such solution will be the Di-VENTIX II multi-format climber, that offers 8 universal inputs (4 universal digital or analog inputs and 4 universal analog inputs); digital image processing from input to output; HDCP compatible; 4 live image layers made up of 4 Climbers, 2K output resolution; digital inputs in SD/HD-SDI, DVI or 3G-SDI and analog V; compound, Y/C, YUV, VGA up to 2K resolution; 8 full picture pictures; 8 Logos + 1 animated logo; luma and Chroma Key; Masks; ace.; titration; Edge Blending with two projectors being able to make up to one image in 4K; horizontal or vertical blending.

It will also display the high-resolution, matrix multilayer mixer with 4 Eikos re-scalers, awarded at ISE 2011 like the “Product for more innovative video distribution or process”. The Eikos is a multilayer mixer/switch/scaler that offers up to 12 Tickets, Including 4 SDI and 2 DVI-D. Eikos offers 3 operating modes: multilayer mixer, native matrix 12×2 QuadraVision modes.

likewise, will display the OPS300 mixer, with program output, pre-output and video recording output; T-bar on the front panel; until 2 Resolution K; 8 universal analog inputs; 2 Digital DVI; 2 SD-HD/SDI, main VGA and DVI output; previous VGA and DVI output; analog SD/HD-TV and SD/HD-SDI recording output; a fixed fund with 2 Live PIP; 8 frames and 8 Logos; DSK at DVI; title and chroma Key, molten, court, curtains and PIP with movement.

New product range
The same, Analog Way to take ISE 2012 Smart Series, a range of solutions that has been designed to offer AV integrators the best of a given functionality with the optimal value for money. One of the products in this range is the Smart MatriX unit, a video array with high-resolution native output and equipped with four climbers. This unit has advanced routing features and numerous effects that make it an interesting solution for applications that require viewing multiple video sources on multiple screens.

The Smart MatriX offers up to 12 Tickets, including four for SDI and two for DVI-D. Through processing 100% digital, provides digital and analog signals, in DVI and VGA (RGBHV) respectively, along with a selection of formats ranging from HDTV to high definition for computers (Computer 2K). The Smart MatriX offers a native 12×2 continuous switching scaling mode in which the mix, between any of the 12 Tickets, can be by cut or by fade, being able to even synchronize for the two outputs.

In addition, offers a number of PIP features (see 2 channels simultaneously on the screen), up to two PIPs can be deployed per output, on static backgrounds. The Smart Matrix also has a built-in stereo audio switch that offers 12 Tickets (eight analogs + four SDI embedded) and two exits. On the other hand, it also has an additional auxiliary input can be combined with any of the outputs. The output card provides SD or HDTV video formats in various signals, from composite video to HD SDI. In addition, by new coupling developed especially by Analog Way (patent pending), Video output can be used with any cable.

The last solution that has come to complete the Smart range is the Smart Quad, an HD mixer that offers seven universal analog inputs, two equipped with DVI and HD-SDI; allows the display of the four video or computer sources in the main output; the display of the four windows can be done according to 12 different pre-programmed presets; different effects and seamless transitions and(zoom, cut, Fade, wipe, slide, smooth movement, Etc.); and a video output that offers SD and HDTV formats in various composite video signals to HD-SDI.

Wide catalogue
You can also see the high-resolution multilayer mixer in Amsterdam and switch with 2 climbers Press, that has a fully digital process. This high-quality, easy-to-use solution is specially suited for projections on large screens, conference rooms and places of worship. Pulse account with 10 direct inputs, 2 DVI and 2 Sdi. In mixer mode, Pulse can present 2 live sources and persdonalize them with various attributes. The built-in audio mixer has 12 Tickets (8 analogue and 4 Embedded SDI) and 2 Outputs.

likewise, will be the axion2 high-end remote control, that has a completely redesigned architecture to better respond to the needs of live applications. Axion2 supports the new generation Analog Way mixer. Machines can be controlled as stand-alone processors or in combination, including soft Edge Blending configurations. Axion2 can control up to 6 separate display configurations in different locations (single view or multiple projectors in edge Blending mode) and store up 90 presets for each screen setup. Thanks to Sequences mode, you can create preset series in up to nine sequences.

At last, Analog Way will exhibit the Orchestra console at ISE, a powerful remote control, intuitive and ergonomic, designed to independently or simultaneously manage various mixers such as Di-VentiX II, OPS300, OPS200, Press, SmartVu and its Light Editions, as well as the new Analog Way Eiks mixers, Smart Matrix and its Light Editions, Smart Edge and Smart Quad. Mixers can be controlled as separate boxes or as any kind of combination, including Edge Blending. Once connected to analog Way mixers, orchestra can control up to 6 separate display configurations in different locations (single view or multiple projectors in Smooth Edge Blending mode) and store up 64 presets for each screen setup.
