Bisou Club nightclub envelops its customers in spectacular decorative lighting

To achieve this effect, about a hundred Elation Professional teams have been installed, including 32 Led ACL 360i effect units, 24 Rayzor Beam 2R moving heads, 12 Units of the Cuepix Batten Led bar and 350 meters of led RGB Flex Pixel WP tape.

The Bisou nightclub, located in the city of Monterrey, in northern Mexico, has opened its doors this spring and its careful lighting design includes numerous units of different Elation Professional, whose brand distributes Visuals, who support and reinforce their décor.

The company Adimsa has been responsible for this lighting project, carried out under the guidance of architect Filipao Nunez and the owners of the Bisou nightclub, brothers Victor and Emilio Califa.

"Both the architect and the owners sought to achieve an elegant and modern atmosphere at the same time, with special emphasis on avant-garde and dynamic lighting design. Elation Professional's numerous appliance units have been installed in the dance floor area but also in areas of the disco where a more decorative and subtle lighting design was needed", explains Edson Rivera of Adimsa.

As the central core of this lighting design have been installed 32 Led ACL 360i effect units, with continuous 360-degree rotation in Pan and Tilt, that form a spectacular matrix of 8 units wide by 4 units high and has been mounted on one of the side walls in the dance floor area of the disco.

Elation's ACL 360i features a 4-degree collimator aperture lens and an RGBW Led module 60 watts of power.

The perimeter of the dance floor area has 6 acl 360 Roller, that with its distinctive light roller effect, provided by its four-sided bar and 5 Led RGB (of 15 watts of power each) per face, offers spectacular effects. Added to this is its 360-degree continuous turn on Pan and Tilt, your individual control over each pixel and its 300 watts of total power.

This area of the dance floor also features 6 Led Elation Protron 3K strobe units, of 80.000 lumens of power.

The award-winning hybrid effect (Beam, Laser Scanner and Simulator) Elation Sniper 2R is also part of this design with 12 units of it mounted in groups of three on the corners of the dance area of the Bisou nightclub and which, alongside 24 Units of the very compact Beam Elation Rayzor Beam 2R type moving head provide effects on high intensity lighting design.

Sniper 2R features the Philips Platinum 2R lamp 132 watts of power and provides a 3-degree beam of aperture with 14 dichroic colors, 17 gobos and prism of 3 Faces, in addition to Scanner effect (with speed control and X/Y travel) and Laser Simulator (with 29 macros with X/Y zoom and rotation).

Rayzor Beam 2R is a moving head that also incorporates the Philips Platinum 2R lamp and offers very fast movements and a 3rd aperture beam, with 13 dichroic colors, 14 gobos and prism of 8 Faces.

likewise, 12 Units of the Cuepix Batten Led Bar, with their individual control over each pixel and its 10 Led tipo COB (Chip-On-Board) RGB 30 watts of power each (for a total of 300 watts of power per bar) bathe in saturated colors different spaces of the disco.

This decorative lighting of this dance floor is reinforced with 350 meters of led RGB Flex Pixel WP tape and spectacular programming with individual control over each pixel (pixel-mapping). This solution, with a length of 3 meters by Led tape (of which have been used 120 units in this facility) Provides 216 DMX channels with individual control over each pixel in the 72 RGB LED that mounts each unit.
